Free online course
InstructorControlByte
Free CODESYS PLC Programming Mini-Course
Start programming PLCs in CODESYS for free - no hardware needed. In six short video lessons you install the environment, write your first ladder logic program, build a self-holding motor circuit with...
InstructorControlByte
What you will learn
- Write your first ladder logic program in CODESYS
- Use NO and NC contacts and coils
- Build a self-holding (latching) motor circuit with a STOP button
- Understand practical differences between Ladder and Structured Text
- Create an HMI visualization and test it in the simulator
Course curriculum
6 lessons · approx. 38 min
1. CODESYS mini-course6 lessons
- Welcome to the CODESYS mini-course 2:15
- Your first ladder logic program - motor ON 7:47
- Ladder vs Structured Text - practical differences 9:59
- Task: latching circuit 5:42
- Adding a STOP button (NC contact) 6:36
- HMI visualization in the simulator 5:55
About the course
Start programming PLCs in CODESYS for free - no hardware needed. In six short video lessons you install the environment, write your first ladder logic program, build a self-holding motor circuit with a STOP button and add a working HMI visualization in the simulator.
After the mini-course you can continue with the full Basic PLC Structured Text Programming Course in CODESYS.
Who it is for
- Electricians and technicians who want to start PLC programming
- Students of automation and electrical engineering
- Anyone who wants to try CODESYS before buying a full course
Requirements
- A Windows PC
- No PLC hardware needed - everything runs in the CODESYS simulator
Start for free today
Create a free account and watch the first lesson right away.
